Machine Material	Mild Steel & Cast Iron
Machine Type	Semi-Automatic
Capacity	40-60 cuts / mint
Weight	150 kg
Usage/Application	Round Corner Cutting
Driven Type	Motorized
Blade Type	R3 to R10 (Interchangeable)
Automation Grade	Semi-Automatic
Voltage	220V AC
Material	Paper, Cardboard, PVC, Notebooks
Power Source	1 Phase
Air Compressor	No
Power Rating	0.75 kW
Production Speed	Up to 3000 cuts per hour
Phase	Single Phase

The Single Side Round Corner Cutting Machine is a heavy-duty, motorized equipment designed to precisely trim the sharp square corners of printed materials into smooth, rounded edges. By automating the punching process, it dramatically increases productivity and ensures a clean, professional finish on bulk orders.
This corner rounding machine is widely utilized in the printing, binding, and packaging industry, perfect for notebooks, diaries, business cards, playing cards, hang tags, and hardcover books.1. Comes with interchangeable cutting knives (ranging from R3 to R10) to achieve different corner radii.
2. Robust cast iron machine frame ensures vibration-free operation and long-lasting durability.
3. Equipped with adjustable side guides to keep paper stacks perfectly aligned for accurate, burr-free cutting.
4. Easy-to-use foot pedal switch allows the operator to keep both hands free for handling materials safely.



Model	RCM-50	RCM-80	RCM-100
Cutting   Thickness	50mm	80mm	100mm
Knife   Radius	R3 - R10	R3 - R10	R3 - R12
Table   Size	300*200mm	400*300mm	450*350mm
Speed	40-60   cycle /minute	40-60   cycle /minute	40-60   cycle /minute
Power	0.75kw	1.1kw	1.5kw
Dimension	600*500*1200mm	700*600*1300mm	800*700*1400mm
Weight	150kg	200kg	250kg
